SUBMERSIBLE CENTRIFUGAL PUMP VTN-1M
In-house design, production and installation.
About the VTN-1M pump
VTN-1M is the pump-mixer of the VTN series: it pumps viscous and contaminated media while actively mixing them in the intake area, so a homogeneous, non-stratified mass enters the line. It is the most compact model of the range and fits where the base pump cannot: versions from 5 kW, an opening from 300×300 mm, weight up to 260 kg. Like the whole series, it handles raw manure from 75% moisture without water dilution.
Key features:
- Two functions in one unit: pumping (200 t/h on liquid manure) plus active mixing within a radius of up to 5 m — no separate mixer to buy and install
- Homogenization breaks up crust and sediment and evens out the consistency: a uniform mass does not settle in pipes, is processed faster and spreads evenly as fertilizer
- The most compact in the range: versions from 5 kW, an installation opening from 300×300 mm, a 1.5 m column, up to 260 kg
- The cutting mechanism at the inlet shears fibres and stalks — no filters or separate shredder needed
- Pumping distance up to 2 km and a head up to 23 m — reaches remote storage like the other modifications of the range
Applications:
- Agriculture: preparing liquid fertilizers with even distribution of components, breaking up crust in receiving tanks and lagoons, pumping manure from 75% moisture.
- Waste handling and treatment plants: homogenizing liquid and semi-liquid waste before further processing, preparing effluents without inlet filters.
- Industrial processing: uniform mixtures and suspensions from dissimilar components, process effluents with sediment.
VTN-1M is the choice when mixing is a task of its own, or when the installation opening is tight. For plain stationary pumping without the mixer function, the base VTN-1 fits; for grid-free sites — the tractor-driven VTN-1MT; and the biggest volumes in the range belong to the VTN-1DU flagship.
A mixer and a pump in one machine
Normally homogenization and pumping mean two pieces of equipment: an agitator and a pump, two installations, two openings, two service points. The VTN-1M does both jobs as one unit: it mixes the mass within a radius of up to 5 m and feeds it into the line homogeneous — 200 t/h on liquid manure. And the compact versions — from 5 kW — pass through an opening from 300×300 mm: where the base pump physically will not fit.
The first item is equipment you will not have to buy: a separate agitator and its installation. The second is water: like the whole series, the VTN-1M moves manure from 75% moisture without dilution. For a 400-cow farm that water costs, by our model, roughly BYN 24,000–53,000 a year (conservative assumptions) — work out your own figure in the calculator, in the Belarus and Russia modes.
Estimate your farm's savings
What the water added to dilute manure costs per year: hauling, electricity, and the water itself.
Norm: 55 kg/head/day at 88.4% moisture; milking parlour effluent 20 l/head/day
Refine the calculation and see the assumptions on the calculator page
- In production since 2007
- More than 100 units installed on farms
- Manufacturer's service in Vitebsk
- Delivery across Belarus and Russia
Installation and commissioning by the manufacturer's own specialists
How a VTN differs from a mass-produced pump
On the left are the manufacturer's passport figures of a mass-produced manure pump; we do not name it. The full six-parameter comparison lives on the page of the base VTN-1 model.
| Parameter | Mass-produced sewage pump from municipal services (manufacturer's passport) | VTN-1M |
|---|---|---|
| Moisture content of the pumped mass | Mass-produced pump (manufacturer's passport)from 86% by the passport; for a thicker mass the passport of another mass-produced unit prescribes dilution with water to the recommended moisture content | VTN-1Mfrom 75% — the whole VTN series works without dilution |
| Unit weight | Mass-produced pump (manufacturer's passport)1,150–1,300 kg | VTN-1Mup to 260 kg — more than four times lighter; the lightest machine in the series |
The left-hand column is the manufacturer's passports of mass-produced manure pumps sold in the CIS; the right-hand one gives our model's figures, which depend on the version and on the route.
VTN-1M technical specifications
| Capacity on liquid manure, t/h | 200 |
| Capacity on viscous manure (85% moisture), t/h | 100 |
| Head, m | up to 23 |
| Electric motor power, kW | 5–18.5 |
| Power supply | 380–400 V |
| Rotation speed, rpm | 1500 |
| Impeller diameter, mm | 100–240 |
| Discharge spigot, mm | 100 |
| Submersion depth, m | from 3 (immersion of the pump end below the liquid surface; built to order) |
| Pump column length (frame to pump end), m | 1.5 (standard; other lengths to order) |
| Max. discharge lift (with extension), m | up to 8 |
| Pumping distance | up to 2 km (depends on flow rate, pipeline diameter, lift and moisture of the mass) |
| Mixing radius in the intake area, m | up to 5 |
| Moisture content of the pumped mass, % | from 75 |
| Max. solid particle size, mm | up to 30 (fibres are not limited — sheared by the cutting mechanism) |
| Media temperature, °C | up to +40 |
| Weight, kg | up to 260 |
| Wetted parts material | steel |
| Bearing lubrication | forced, any grease grade |
| Min. installation opening, mm | from 300×300 (compact versions) |
| Warranty | 12 months |
The 200 t/h capacity and the head up to 23 m refer to different duty modes; we match the working combination to your tank and pipeline.
Reviews from farms
These letters of thanks and reviews were addressed to the manufacturer of the series, VitTechNasos LLC; today the VTN series is built by NPO-Organika, the successor to that manufacturer.
“The crew was equipped with everything needed — tools and equipment alike — for the personnel to do the work to a proper standard. Throughout the work the client's wishes were taken into account as fully as possible.”
Demonstration of VTN-1M Submersible Pump-Mixer Operation
The video presents the operation of the VTN-1M submersible centrifugal pump manufactured by NPO-Organika — specialized equipment for pumping and intensive mixing of various liquid and viscous media.
Installation and site preparation
- Installation is done by the manufacturer. Supply, installation and commissioning under a single contract: we deliver, install, start the equipment up and hand over a working station under an acceptance certificate. Replacing old equipment is possible — dismantling it is our job.
- What the customer prepares before the installers arrive: a concreted pad by the manure collector and a cleaned receiving tank. We send the requirements once the order is placed — for your own scheme.
- Power connection. The pump is connected to a 380–400 V supply through a control panel; the panel, the cable and the protective switchgear are part of the scope of supply agreed for the order.
- Servicing without a crane. To lift the pump for servicing, the station comes with a portal or a jib crane with a hoist — the pump is raised by your own people, no mobile crane required.
- The first start-up is carried out by our specialists during commissioning; the customer receives the operating manual and the servicing schedule.
VTN-1M — frequently asked questions
Why a pump-mixer, if the VTN-1 mixes as well?
On the base VTN-1, mixing is a by-product of intake; VTN-1M is built for homogenization as a task of its own: it breaks up crust and sediment and evens out the consistency. It is also more compact: an installation opening from 300×300 mm against 600×600 for the VTN-1.
What media does the VTN-1M handle?
Manure from 75% moisture, liquid and semi-liquid waste ahead of treatment plants, emulsions and suspensions — wherever the output must be a uniform, non-stratified mix.
How far does the VTN-1M pump?
Up to 2 km through the pressure line; the actual distance depends on flow rate, pipeline diameter, lift and moisture of the mass. Head is up to 23 m, capacity is 200 t/h on liquid manure.
Why is there no price on the site, and how do I buy a VTN-1M?
There are many versions: 5–18.5 kW of power, a 100–240 mm impeller, a build to suit the tank — and the price follows the configuration. Main versions and components are in stock; for your tank we will select the power and the column and cable lengths. We work on prepayment; price on request via the form or by phone, with the configuration chosen by the manufacturer's engineer. Warranty and service are factory-backed: 12 months, repairs by the manufacturer.
Who does the installation?
The manufacturer's specialists — with warranty and post-warranty service across Belarus and spare parts from stock. From the review by Antonovka-Agro SPU (No. 933 of 1 April 2025): “The work was carried out… with dependable quality and within the agreed deadline”.
Price on request: the configuration is assembled for your site. Leave a request and an engineer will select the right version and quote the price.
